Fully-sealed optical engine
Durable with fine picture quality
The fully-sealed optical engine adopts a high-definition optical lens featuring excellent light transmission, projecting clearer images with high colour accuracy to reproduce the true artistic beauty of films.
Sealed and dustproof
The fully-sealed optical engine effectively prevents dust from entering the inner display, ensuring a longer service life.
High-efficiency heat dissipation
Featuring a built-in low-noise dual-loop cooling system, it provides quiet and efficient heat dissipation for an immersive viewing experience.
200 ISO Lumens
Accurate brightness representation
With SGS international standard luminous flux efficiency certification*, it boasts a brightness of up to 200 ISO Lumens, ensuring accurate brightness representation and more visible details.
1080p physical resolution
Higher definition for a better experience
Featuring 1080p HD resolution with support for 4K video playback with crystal-clear images.
120-inch ultra-wide screen
Ultra-immersive viewing experience
With a 1.2:1 throw ratio, you can project a large screen ranging from 40 to 120 inches anytime, anywhere.
Omnidirectional automatic keystone correction
Project a rectangular image with ease
Equipped with a self-developed keystone AI intelligent algorithm that automatically corrects the image based on the projector's placement, it eliminates the need for repeated manual adjustments. Whether projecting from the front, side, or ceiling, you can instantly achieve a rectangular image.
Auto-focusing
Instantly clear images
The integrated zoom motor can focus quickly even when the projector is moved, so images are always crystal-clear.
Automatic obstacle avoidance
Instantly present the whole image
Equipped with an AI algorithm, the high-precision camera cleverly avoids obstacles such as wall switches and picture frames, determining a suitable area for projection to ensure the completeness of the image.
Auto screen alignment
Quick identification for precise projection
The smart alignment algorithm automatically identifies the edges of the screen to accurately project the image, thus eliminating the need for manual adjustment.
Google TV brings together 400,000+ movies, shows, and more across 10,000+ apps - organised all in one place.
Equipped with built-in full-range dual speakers with Dolby Audio professional-grade certification for a cinematic audiovisual experience*.
The Bluetooth remote control covers a comprehensive 360° with almost no blind spots. Access your favourite content in an instant with shortcuts.
Items Dimensions: 118 × 142 × 176mm
Weight: 1.2kg
Display Technology: LCD
Brightness: 200 ISO Lumens
Resolution: 1920 × 1080P
Throw Ratio: 1.2:1
Screen Dimensions: 40"~120"(Recommend: 60"-100")
Focus: Auto Focus
Keystone Correction: Auto Keystone Correction
Intelligent Obstacle Avoidance: Support
Intelligent Screen Alignment: Support
Projection Method:
Forward, Side, Overhead (15°)
Processor:
MT9630 high-performance chip platform
Built-in Storage:
2 GB DDR3/16 GB eMMC
System: Android TV OS
Mirroring Display: Google Cast
Bluetooth: Bluetooth 5.0
Wireless Connectivity:
Wi-Fi IEEE 802.11 a/b/g/n/ac 2.4 GHz/5 GHz
Audio Effects: Dolby Audio
Speaker: 3W full-range × 2
Rated power: ≤ 72.0W
Standby Power: ≤ 0.50W
Auto power off: Support
Input: 19.0V ⎓ 3.79A
Noise:
≤ 30 dB(A) (Theater mode at an ambient temperature of 25°C)
Storage Temperature/Humidity:
-20℃ to 55℃ ≤ 90%RH
Operating Temperature/Humidity
0℃ to 40℃ / 20%RH–80%RH
